Hitachi

Compact Excavator

ZX50U-5N

Request a Quote

The ZX50U-5N is small and compact and gives you huge performance on all kinds of jobs. We’ve reduced the size and footprint without sacrificing the Hitachi qualities you’ve come to expect – efficiency, reliability and durability.

Product Highlights

  • The Yanmar diesel engine meets EPA Final Tier 4 (FT4)/EU Stage IV emission regulations. It’s easy to maintain and requires no special additional fluids – just ultra-low-sulfur diesel fuel and CJ-4 engine oil.
  • The rubber tracks traverse virtually any terrain, including paved surfaces.
  • Heavy-duty X-frame provides a solid, stable platform that resists material and dirt build-up.
  • Standard quick-coupler equipped boom-mounted auxiliary hydraulic lines make attachment hook-up a snap. Wedge-style coupler enables quick changes and a wide variety of buckets and attachments, such as breakers and augers.
  • Heavy-duty shields deflect material and impacts, protecting the boom/blade cylinders and drive motors.

Product Documents

Specifications

EngineYanmar 4TNV88C
Net Power 26.8 kW (35.9 hp) at 2,400 rpm
Operating Weight 4790 kg (10,560 lb)
Max Dig Reach 5.96 m (19 ft 7 in)
Max Dig Depth3.53 m (11 ft 7 in)
Swing Speed9.0 rpm
Arm Force21.0 kN (4,718 lb)
Bucket Force36.8 kN (8,267 lb)
