Felling Heads
5000/5300/5600 Bunching Saw
The 5000/5300/5600 series saw for drive-to-tree feller bunchers is best suited to pine and eucalyptus row thinning and clear fell applications with a stem diameter range of 205 to 500 mm (8 to 20 in).
Tigercat bunching saws increase the productivity of the entire harvesting system while reducing cost per tonne. Feller buncher productivity and efficiency improves because more trees are cut per cycle, reducing unnecessary machine travel. Skidder productivity and efficiency improves because the bunches are large, well aligned and easy to pick up.
Product Highlights
- Improves both feller buncher and skidder productivity by increasing number of cut stems per cycle and by laying down tight, parallel aligned skidder bunchers
- More cutting and less machine travel; the unique two-arm design allows more trees to be stored before stopping to dump the accumulated bunch
- Twin post design with offset pocket for excellent visibility
- Deep accumulating pocket places the load closer to the machine for improved stability
- Recessed saw blade and clever guarding reduce the throw angle and deflect chips downward, decreasing saw recovery time
Product Documents
Specifications
| 5000 | 5300 | 5600 | |
|---|---|---|---|
| Height – less skisn | 2 460 mm (97 in) | 2 625 mm (103 in) | 2 690 mm (106 in) |
| Width | 1 650 mm (65 in) | 1 765 mm (69 in | 1 800 mm (71 in) |
| Depth | 1 575 mm (62 in | 1 655 mm (65 in) | 1 750 mm (69 in) |
| Front Opening | 860 mm (34 in) | 900 mm (36 in) | 965 mm (38 in) |
| Between Skis | 965 mm (38 in) | 1 070 mm (42 in) | 1 090 mm (43 in) |
| Base Weight | 2 155 kg (4,750 lb) | 2 650 kg (5,850 lb) | 2 630 kg (5,800 lb) |
| Single Cut Capacity | 510 mm (20 in) | 545 mm (21.5 in) | 585 mm (23 in) |
| Accumulating Area | 0,52 m2 (5.6 ft2) | 0,62 m2 (6.7 ft2) | 0,68 m2 (7.3 ft2) |
| Stem Capacity | (11) trees 15 cm (6 in) diameter | (13) trees 15 cm (6 in) diameter | (13) trees 15 cm (6 in) diameter (10) |
| DISC Series 74 | 1 285 mm (50.5 in) diameter | 1 370 mm (54 in) diameter | 1 450 mm (57 in) diameter |
| Kerf | 57 mm (2.25 in) | 57 mm (2.25 in) | 57 mm (2.25 in) |
| Teeth | (16) RotatablenCarbide or hardened stee | (18) RotatablenCarbide or hardened steeln | (18) RotatablenCarbide or hardened steel |
| Motor | 160 cc | 160 cc | 160 cc |
| Blade Speed | 1,275 rpm | 1,150 rpm | 1,150 rpm |
